36-44 Terminal X49/7 Bus Control
Range: Function:
0 % [0 - 100 %] This parameter contains the output level of
*
terminal X49/7 if the terminal is controlled by
a fieldbus.
36-45 Terminal X49/7 Timeout Preset
Range: Function:
0 % [0 - 100 %] The frequency converter sends the value of
*
this parameter to the output terminal when
the terminal is controlled by a fieldbus and a
timeout is detected.
3.26.3 36-5* Output X49/9
Use the parameters in this group to configure the mode of
®
inputs and outputs of VLT Programmable I/O MCB 115.
36-50 Terminal X49/9 Analogue Output
Select the functionality of terminal X49/9.
Option:
[0] No operation
*
[52] MCO 0-20mA/0-10V
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[139] Bus ctrl. 0-20 mA
[141] Bus ctrl 0-20mA t.o.
36-52 Terminal X49/9 Min. Scale
Range: Function:
0 % [0 - Match the minimum output of terminal X49/9
*
200 %] with a required value. For more information,
see parameter 36-42 Terminal X49/7 Min. Scale.
36-53 Terminal X49/9 Max. Scale
Range: Function:
100 % [0 - Scale the maximum output of terminal
*
200 %] X49/9. For more information, see
parameter 36-43 Terminal X49/7 Max. Scale.
36-54 Terminal X49/9 Bus Control
Range: Function:
0 % [0 - 100 %] This parameter contains the output level of
*
terminal X49/9 if the terminal is controlled by
a fieldbus.
MG33MO02
Programming Guide
36-55 Terminal X49/9 Timeout Preset
Range:
0 %
*
3.26.4 36-6* Output X49/11
Use the parameters in this group to configure the mode of
inputs and outputs of VLT
36-60 Terminal X49/11 Analogue Output
Select the functionality of terminal X49/11.
Option:
[0]
*
[52]
[100]
[101]
[102]
Function:
[103]
[104]
[105]
[106]
[107]
[108]
[109]
[139]
[141]
36-62 Terminal X49/11 Min. Scale
Range:
0 %
*
200 %]
36-63 Terminal X49/11 Max. Scale
Range:
100 %
*
Danfoss A/S © 01/2018 All rights reserved.
Function:
[0 - 100 %] The frequency converter sends the value of
this parameter to the output terminal when
the terminal is controlled by a fieldbus and a
timeout is detected.
®
Programmable I/O MCB 115.
No operation
MCO 0-20mA/0-10V
Output frequency
Reference
Feedback
Motor Current
Torque rel to limit
Torq relate to rated
Power
Speed
Torque
Max Out Freq
Bus ctrl. 0-20 mA
Bus ctrl 0-20mA t.o.
Function:
[0 - Match the minimum output of terminal
X49/11 with a required value. For more
information, see parameter 36-42 Terminal
X49/7 Min. Scale.
Function:
[0 - Scale the maximum output of terminal
200 %] X49/11. For more information, see
parameter 36-43 Terminal X49/7 Max. Scale.
3 3
Function:
