Parameter Descriptions
Digital input function Select
Counter B (down) [64]
Reset counter B [65]
Mech. brake feedb. [70]
Mech. brake feedb. inv. [71]
PID error inv. [72]
PID reset I-part [73]
PID enable [74]
MCO specific [75]
PTC card 1 [80]
PROFIdrive OFF2 [91]
PROFIdrive OFF3 [92]
Light load detection [94]
Mains Loss [96]
Mains loss inverse [97]
Start edge triggered [98]
Safety option reset [100]
Enable master offset [108]
Start virtual master [109]
Start homing [110]
Activate touch [111]
Relative position [112]
Enable reference [113]
Sync. to Pos. Mode [114]
Home sensor [115]
Home sensor inverse [116]
Touch sensor [117]
Touch sensor inverse [118]
Speed mode [119]
Power Limit Mot. [231]
Power Limit Gen. [232]
Power Limit Both [233]
Table 3.15 Digital Input Function
®
VLT AutomationDrive FC 301/FC 302 standard terminals
are 18, 19, 27, 29, 32, and 33. VLT
MCB 101 terminals are X30/2, X30/3, and X30/4.
Terminal 29 functions as an output only in FC 302.
Functions dedicated to only 1 digital input are stated in
the associated parameter.
All digital inputs can be programmed to these functions:
[0] No No reaction to signals transmitted to the
operation terminal.
[1] Reset Resets frequency converter after a trip/alarm.
Not all alarms can be reset.
[2] Coast (Default digital input 27): Coast stop, inverted
inverse input (NC). The frequency converter leaves the
motor in free mode. Logic 0⇒coast stop.
[3] Coast and Reset and coast stop inverted input (NC).
reset Leaves motor in free mode and resets
inverse
MG33MO02
Programming Guide
Terminal
29, 33
All
All
All
All
All
All
All
All
All
All
All
32, 33
32, 33
All
–
All
All
All
All
All
All
All
18, 32, 33
18, 32, 33
18, 32, 33
18, 32, 33
All
All
All
All
®
General Purpose I/O
Danfoss A/S © 01/2018 All rights reserved.
frequency converter. Logic 0⇒coast stop and
reset.
[4] Quick stop Inverted input (NC). Generates a stop in
inverse accordance with quick stop ramp time set in
parameter 3-81 Quick Stop Ramp Time. When
the motor stops, the shaft is in free mode.
Logic 0⇒quick stop.
[5] DC brake Inverted input for DC brake (NC). Stops motor
inverse by energizing it with a DC current for a certain
time period. See parameter 2-01 DC Brake
Current to parameter 2-03 DC Brake Cut In Speed
[RPM]. The function is only active when the
value in parameter 2-02 DC Braking Time is
different from 0. Logic 0⇒DC brake.
[6] Stop Stop inverted function. Generates a stop
inverse function when the selected terminal goes from
logical level 1 to logical level 0.
The stop is performed according to the
selected ramp time:
•
Parameter 3-42 Ramp 1 Ramp Down
Time,
•
Parameter 3-52 Ramp 2 Ramp down
Time,
•
Parameter 3-62 Ramp 3 Ramp down
Time, and
•
Parameter 3-72 Ramp 4 Ramp Down
Time.
NOTICE
When the frequency converter is at the
torque limit and has received a stop
command, it may not stop by itself. To
ensure that the frequency converter
stops, configure a digital output to [27]
Torque limit and stop. Connect this digital
output to a digital input that is
configured as coast.
[8] Start (Default digital input 18): Select start for a
start/stop command. Logic 1 = start,
logic 0 = stop.
[9] Latched If a pulse is applied for minimum 2 ms, the
start motor starts. The motor stops when stop
inverse is activated, or a reset command (via
DI) is given.
[10] Reversing (Default digital input 19). Change the direction
of motor shaft rotation. Select logic 1 to
reverse. The reversing signal only changes the
direction of rotation. It does not activate the
start function. Select both directions in
parameter 4-10 Motor Speed Direction. The
function is not active in process closed loop.
[11] Start Used for start/stop and for reversing on the
reversing same wire. Signals on start are not allowed at
the same time.
3 3
89
