Parameter Descriptions
[45] Bus Ctrl Controls output via bus. The state of the
output is set in parameter 5-90 Digital &
Relay Bus Control. If a bus timeout occurs,
the output state is retained.
[46] Bus Ctrl On at Controls output via bus. The state of the
timeout output is set in parameter 5-90 Digital &
Relay Bus Control. If a bus timeout occurs,
the output state is set high (on).
[47] Bus Ctrl Off at Controls output via bus. The state of the
timeout output is set in parameter 5-90 Digital &
Relay Bus Control. If a bus timeout occurs,
the output state is set low (off).
[51] MCO-controlled Active when a VLT
Controller MCO 102 or VLT
Control MCO 305 is connected. The
output is controlled from option.
[55] Pulse output
[60] Comparator 0 See parameter group 13-1* Comparators. If
comparator 0 is evaluated as true, the
output goes high. Otherwise, it is low.
[61] Comparator 1 See parameter group 13-1* Comparators. If
Comparator 1 is evaluated as true, the
output goes high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1* Comparators. If
comparator 2 is evaluated as true, the
output goes high. Otherwise, it is low.
[63] Comparator 3 See parameter group 13-1* Comparators. If
comparator 3 is evaluated as true, the
output goes high. Otherwise, it is low.
[64] Comparator 4 See parameter group 13-1* Comparators. If
comparator 4 is evaluated as true, the
output goes high. Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1* Comparators. If
comparator 5 is evaluated as true, the
output goes high. Otherwise, it is low.
[70] Logic Rule 0 See parameter group 13-4* Logic Rules. If
logic rule 0 is evaluated as true, the
output goes high. Otherwise, it is low.
[71] Logic Rule 1 See parameter group 13-4* Logic Rules. If
logic rule 1 is evaluated as true, the
output goes high. Otherwise, it is low.
[72] Logic Rule 2 See parameter group 13-4* Logic Rules. If
logic rule 2 is evaluated as true, the
output goes high. Otherwise, it is low.
[73] Logic Rule 3 See parameter group 13-4* Logic Rules. If
logic rule 3 is evaluated as true, the
output goes high. Otherwise, it is low.
[74] Logic Rule 4 See parameter group 13-4* Logic Rules. If
logic rule 4 is evaluated as true, the
output goes high. Otherwise, it is low.
[75] Logic Rule 5 See parameter group 13-4* Logic Rules. If
logic rule 5 is evaluated as true, the
output goes high. Otherwise, it is low.
[80] SL Digital See parameter 13-52 SL Controller Action.
Output A The output goes high whenever the
smart logic action [38] Set dig. out. A high
MG33MO02
Programming Guide
[81]
[82]
®
Advanced Cascade
®
Motion
[83]
[84]
[85]
[90]
[96]
[98]
[120] Local reference
Danfoss A/S © 01/2018 All rights reserved.
is executed. The output goes low
whenever the smart logic action [32] Set
dig. out. A low is executed.
SL Digital See parameter 13-52 SL Controller Action.
Output B The input goes high whenever the smart
logic action [39] Set dig. out. B high is
executed. The input goes low whenever
the smart logic action [33] Set dig. out. B
low is executed.
SL Digital See parameter 13-52 SL Controller Action.
Output C The input goes high whenever the smart
logic action [40] Set dig. out. C high is
executed. The input goes low whenever
the smart logic action [34] Set dig. out. C
low is executed.
SL Digital See parameter 13-52 SL Controller Action.
Output D The input goes high whenever the smart
logic action [41] Set dig. out. D high is
executed. The input goes low whenever
the smart logic action [35] Set dig. out. D
low is executed.
SL Digital See parameter 13-52 SL Controller Action.
Output E The input goes high whenever the smart
logic action [42] Set dig. out. E high is
executed. The input goes low whenever
the smart logic action [36] Set dig. out. E
low is executed.
SL Digital See parameter 13-52 SL Controller Action.
Output F The input goes high whenever the smart
logic action [43] Set dig. out. F high is
executed. The input goes low whenever
the smart logic action [37] Set dig. out. F
low is executed.
kWh counter Sends a pulse (200 ms pulse width) to
pulse output terminal whenever kWh counter
changes (parameter 15-02 kWh Counter).
NOTICE
Reverse After
Ramp
This option is available only with
software version 48.XX.
Indicates if the direction of rotation
should be reversed. Depends on whether
the speed reference is positive or
negative after the ramp specified in
parameter 16-48 Speed Ref. After Ramp
[RPM].
NOTICE
Virtual Master
Dir.
This option is available only with
software version 48.XX.
A virtual master signal that controls the
rotation direction of followers.
Output is high when
active parameter 3-13 Reference Site = [2] Local.
