Parameter Descriptions
[107] Speed
[108] Torque
[109] Max. out freq
5-60 Terminal 27 Pulse Output Variable
Option:
3 3
[0] No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[97] Reference After
Ramp
[99] Virtual Master
Speed
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-62 Pulse Output Max Freq #27
Range:
5000. Hz [0 - 32000
*
Hz]
5-63 Terminal 29 Pulse Output Variable
Option:
108
®
VLT AutomationDrive FC 301/302
Function:
Select the display output for terminal
27.
NOTICE
This option is available only with
software version 48.XX.
Actual speed reference after the ramp.
Use this output as master signal for
speed synchronization of follower
frequency converters. The reference is
set in parameter 16-48 Speed Ref. After
Ramp [RPM].
NOTICE
This option is available only with
software version 48.XX.
Virtual master signal for controlling
the speed or position of the followers.
Function:
Set the maximum frequency for
terminal 27 corresponding to the
output variable selected in
parameter 5-60 Terminal 27 Pulse Output
Variable.
Function:
NOTICE
This parameter is available for FC
302 only.
Danfoss A/S © 01/2018 All rights reserved.
5-63 Terminal 29 Pulse Output Variable
Option: Function:
[0] No operation Select the display output for terminal
29.
[45] Bus ctrl.
[48] Bus ctrl., timeout
NOTICE
[97] Reference After
Ramp
This option is available only with
software version 48.XX.
Actual speed reference after the ramp.
Use this output as master signal for
speed synchronization of follower
frequency converters. The reference is
set in parameter 16-48 Speed Ref. After
Ramp [RPM].
NOTICE
[99] Virtual Master
Speed
This option is available only with
software version 48.XX.
Virtual master signal for controlling the
speed or position of the followers.
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-65 Pulse Output Max Freq #29
Range: Function:
Size [0 - 110000 Set the maximum frequency for
related Hz] terminal 29 corresponding to the
*
output variable set in
parameter 5-63 Terminal 29 Pulse
Output Variable.
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for readout on terminal X30/6.
This parameter is active when VLT
is installed in the frequency converter.
Same options and functions as parameter group 5-6* Pulse
Outputs.
Option: Function:
[0] No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
®
General Purpose I/O MCB 101
