Parameter Descriptions
7-51 Process PID Feed Fwd Gain
Range: Function:
parameter 7-51 Process PID Feed Fwd Gain has more
options. In winder applications, the feed-forward
factor is typically the line speed of the system.
3 3
7-52 Process PID Feed Fwd Ramp up
Range:
0.01 s [0.01 - 10 s] Controls the dynamics of the feed-forward
*
7-53 Process PID Feed Fwd Ramp down
Range:
0.01 s [0.01 - 10 s] Controls the dynamics of the feed-forward
*
7-56 Process PID Ref. Filter Time
Range:
0.001 s [0.001 - 1
*
s]
7-57 Process PID Fb. Filter Time
Range:
0.001 s [0.001 - 1
*
s]
3.8.9 7-9* Position PI Ctrl.
Parameters for configuring the position controller.
7-90 Position PI Feedback Source
Option:
[0] Motor
*
feedb.
P1-02
[1] 24V
encoder
130
VLT
Function:
signal when ramping up.
Function:
signal when ramping down.
Function:
Set a time constant for the reference first-
order low-pass filter. The low-pass filter
improves steady-state performance and
dampens oscillations on the reference/
feedback signals. However, severe filtering
can be detrimental to dynamic
performance.
Function:
Set a time constant for the feedback first-
order low-pass filter. The low-pass filter
improves steady-state performance and
dampens oscillations on the reference/
feedback signals. However, severe filtering
can be detrimental to dynamic
performance.
Function:
NOTICE
This parameter is only available with
software version 48.XX.
Select the feedback source for the position PI
controller.
Use the feedback source selected as motor
feedback in parameter 1-02 Flux Motor Feedback
Source. In flux sensorless control principle the
estimated position from motor control is used.
A 24 V encoder connected to terminals 32, 33.
