Parameter Descriptions
5-40 Function Relay
Option:
[96] Reverse After
3 3
Ramp
[98] Virtual Master Dir.
[120] Local ref active
[121] Remote ref active
[122] No alarm
[123] Start command
activ
104
®
VLT AutomationDrive FC 301/302
Function:
action [37]. Output F is high on smart
logic action [43].
NOTICE
This option is available only with
software version 48.XX.
See the description in
chapter 3.6.3 5-3* Digital Outputs.
NOTICE
This option is available only with
software version 48.XX.
See the description in
chapter 3.6.3 5-3* Digital Outputs.
Output is high when
parameter 3-13 Reference Site = [2]
Local or when parameter 3-13 Reference
Site = [0] Linked to hand auto at the
same time as the LCP is in hand-on
mode.
Reference site Local Remote
set in referenc reference
parameter 3-13 e active
Reference Site active [121]
[120]
Reference site: 1
Local
parameter 3-13 R
eference Site [2]
Local
Reference site: 0
Remote
parameter 3-13 R
eference Site [1]
Remote
Reference site:
Linked to Hand/
Auto
Hand 1
Hand⇒off 1
Auto⇒off 0
Auto 0
Table 3.21 Local Reference Active
Output is high when
parameter 3-13 Reference Site = [1]
Remote or [0] Linked to hand/auto while
the LCP is in auto-on mode. See
Table 3.21.
Output is high when no alarm is
present.
Output is high when the start
command is high (that is via digital
input, bus connection, [Hand On], or
Danfoss A/S © 01/2018 All rights reserved.
5-40 Function Relay
Option:
[124] Running reverse
[125] Drive in hand
mode
[126] Drive in auto
mode
[151] ATEX ETR cur.
alarm
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur.
warning
0
[154] ATEX ETR freq.
warning
1
[188] AHF Capacitor
Connect
[189] External Fan
Control
0
0
[190] Safe Function
0
active
1
[191] Safe Opt. Reset
req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
Function:
[Auto On]), and a stop has been last
command.
Output is high when the frequency
converter is running counterclockwise
(the logical product of the status bits
running AND reverse).
Output is high when the frequency
converter is in hand-on mode (as
indicated by the LED light above
[Hand On]).
Output is high when the frequency
converter is in auto-on mode (as
indicated by LED on above [Auto On]).
Selectable if parameter 1-90 Motor
Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR. If alarm 164,
ATEX ETR cur.lim.alarm is active, the
output is 1.
Selectable if parameter 1-90 Motor
Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR. If alarm 166,
ATEX ETR freq.lim.alarm is active, the
output is 1.
Selectable if parameter 1-90 Motor
Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR. If alarm 163,
ATEX ETR cur.lim.warning is active, the
output is 1.
Selectable if parameter 1-90 Motor
Thermal Protection is set to [20] ATEX
ETR or [21] Advanced ETR. If warning
165, ATEX ETR freq.lim.warning is active,
the output is 1.
The internal logics for the internal fan
control is transferred to this output to
make it possible to control an external
fan (relevant for HP duct cooling).
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
