How to Program
Another easy way of commissioning the frequency
converter is by using the smart application set-up (SAS),
2 2 which can also be found by pressing [Quick Menu]. To set
up the applications listed, follow the instructions on the
successive screens.
The [Info] key can be used throughout the SAS to see help
information for various selections, settings, and messages.
The following 3 applications are included:
•
Mechanical brake.
•
Conveyor.
•
Pump/fan.
The following 4 fieldbusses can be selected:
•
PROFIBUS.
•
PROFINET.
•
DeviceNet.
•
EtherNet/IP.
NOTICE
The frequency converter ignores the start conditions
when SAS is active.
NOTICE
The smart set-up runs automatically on the first power-
up of the frequency converter or after a reset to factory
settings. If no action is taken, the SAS screen automat-
ically disappears after 10 minutes.

2.1.8 Main Menu Mode

Press [Main Menu] to enter the main menu mode. The
readout in Illustration 2.14 appears on the display.
The middle and bottom sections in the display show a list
of parameter groups, which can be selected by toggling
▲ ▼
the [ ] and [
Illustration 2.14 Main Menu Mode
Each parameter has a name and number which remain the
same regardless of the programming mode. In the main
menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
18
] keys.
1107 RPM 3.84 A
Main Menu
0-** Operation/Display
1-** Load/Motor
2-** Brakes
3-** References/Ramps
Danfoss A/S © 01/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302
All parameters can be changed in the Main Menu.
However, depending on the choice of configuration
(parameter 1-00 Configuration Mode), some parameters can
be hidden. For example, open loop hides all the PID
parameters, and other enabled options make more
parameter groups visible.

2.1.9 Parameter Selection

In the main menu mode, the parameters are divided into
groups. Select a parameter group with the navigation keys.
After selecting a parameter group, select a parameter with
the navigation keys.
The middle section on the display shows the parameter
number and name, and the selected parameter value.
Illustration 2.15 Parameter Selection

2.1.10 Changing Data

The procedure for changing data is the same in the quick
menu mode and the main menu mode. Press [OK] to
change the selected parameter.
The procedure for changing data depends on whether the
selected parameter represents a numeric data value or a
text value.

2.1.11 Changing a Text Value

1(1)
If the selected parameter is a text value, change the text
value with the [
Place the cursor on the value to save and press [OK].
Illustration 2.16 Changing a Text Value
740RPM 10.64A
Basic Settings
0 -01 Language
[0] English
▲ ▼
] [ ] keys.
740RPM 10.64 A
Basic Settings
0 -01 Language
[0] English
1 [1]
0-0 *
1 [1]
0-0 *
