Parameter Descriptions
5-32 Term X30/6 Digi Out (MCB 101)
Option:
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
3 3
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[84] SL digital output E
[85] SL digital output F
[90] kWh counter pulse
[96] Reverse After Ramp
[98] Virtual Master Dir.
[120] Local ref active
[121] Remote ref active
[122] No alarm
[123] Start command activ
[124] Running reverse
[125] Drive in hand mode
[126] Drive in auto mode
[151] ATEX ETR cur. alarm
[152] ATEX ETR freq. alarm
[153] ATEX ETR cur. warning
[154] ATEX ETR freq. warning
[188] AHF Capacitor Connect
[189] External Fan Control
[190] Safe Function active
[191] Safe Opt. Reset req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
[222] Homing Ok
[223] On Target
100
®
VLT AutomationDrive FC 301/302
Function:
Sends a pulse (200 ms pulse
width) to output terminal
whenever kWh counter changes
(parameter 15-02 kWh Counter).
NOTICE
This option is available only
with software version 48.XX.
NOTICE
This option is available only
with software version 48.XX.
NOTICE
This option is available only
with software version 48.XX.
NOTICE
This option is available only
with software version 48.XX.
Danfoss A/S © 01/2018 All rights reserved.
5-32 Term X30/6 Digi Out (MCB 101)
Option: Function:
NOTICE
[224] Position Error
This option is available only
with software version 48.XX.
NOTICE
[225] Position Limit
This option is available only
with software version 48.XX.
NOTICE
[226] Touch on Target
This option is available only
with software version 48.XX.
NOTICE
[227] Touch Activated
This option is available only
with software version 48.XX.
5-33 Term X30/7 Digi Out (MCB 101)
Option: Function:
[0] No operation This parameter is active when
*
option module VLT
Purpose I/O MCB 101 is mounted
in the frequency converter.
Functions are described in
parameter group 5-3* Digital
Outputs.
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] VLT running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready,no thermal W
[23] Remote,ready,no TW
[24] Ready, Voltage OK
[25] Reverse
®
