Parameter Descriptions
1-07 Motor Angle Offset Adjust
Range:
3 3
0 [Manual] The functionality of this option depends on the
*
[1] Auto
[2] Auto
Every
Start
[3] Off
[4] Once with
Store
3.2.2 1-1* Special Settings
NOTICE
The parameters within this parameter group cannot be
adjusted while the motor is running.
3.2.3 Asynchronous Motor Set-up
Enter the following motor data. Find the information on
the motor nameplate.
1. Parameter 1-20 Motor Power [kW] or
parameter 1-21 Motor Power [HP].
2. Parameter 1-22 Motor Voltage.
3. Parameter 1-23 Motor Frequency.
4. Parameter 1-24 Motor Current.
5. Parameter 1-25 Motor Nominal Speed.
36
VLT
Function:
NOTICE
This parameter is only valid for FC 302
and only in combination with a PM motor
with feedback.
type of the feedback device. This option sets the
frequency converter to use the motor angle
offset entered in parameter 1-41 Motor Angle
Offset, if an absolute feedback device is used.
If an incremental feedback device is selected, the
frequency converter automatically adjusts the
motor angle offset on the first start after power-
up, or when the motor data is changed.
The frequency converter adjusts the motor angle
offset automatically on the first start after power-
up, or when the motor data is changed no
matter what feedback device is selected. This
means that options Manual and Auto are
identical for the incremental encoder.
The frequency converter adjusts the motor angle
offset automatically on every start, or when the
motor data is changed.
Selecting this option turns the automatic offset
adjustment off.
This option updates parameter 1-41 Motor Angle
Offset automatically when the angle value is 0.
This option is valid only for absolute feedback
devices. The function uses rotor detection and
then applies DC hold to make the offset
adjustment more accurate.
