Parameter Descriptions
6-12 Terminal 53 Low Current
Range:
Function:
0.14
[0.00 -
Enter the low current value. This reference
mA
par. 6-13
signal should correspond to the minimum
*
mA]
reference value, set in
parameter 3-02 Minimum Reference. Set the
value to exceed 2 mA in order to activate the
live zero timeout function in
parameter 6-01 Live Zero Timeout Function.
6-13 Terminal 53 High Current
Range:
Function:
20 mA
[ par. 6-12 -
Enter the high current value
*
20 mA]
corresponding to the high reference/
feedback set in parameter 6-15 Terminal 53
High Ref./Feedb. Value.
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0 ReferenceFeed-
[-999999.999 -
backUnit
999999.999
*
ReferenceFeed-
backUnit]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
1500.000
[-999999.999 -
ReferenceFeed-
999999.999
backUnit
ReferenceFeed-
*
backUnit]
6-16 Terminal 53 Filter Time Constant
Range:
Function:
NOTICE
0.001 s
[0.001 - 10
*
s]
This parameter cannot be adjusted
while the motor is running.
Enter the filter time constant. This
constant is a first-order digital low-pass
filter time for suppressing electrical noise
in terminal 53. A high value improves
dampening but also increases the delay
through the filter.
MG33MO02
Programming Guide
Function:
Enter the analog input
scaling value that
corresponds to the low
voltage/low current set in
parameter 6-10 Terminal 53
Low Voltage and
parameter 6-12 Terminal 53
Low Current.
Function:
Enter the analog input
scaling value that
corresponds to the
maximum reference
feedback value set in
parameter 6-11 Terminal 53
High Voltage and
parameter 6-13 Terminal 53
High Current.
Danfoss A/S © 01/2018 All rights reserved.
3.7.3 6-2* Analog Input 2
Parameters for configuring the scaling and limits for analog
input 2 (terminal 54).
6-20 Terminal 54 Low Voltage
Range:
Function:
0.07 V
[-10.00 -
Enter the low voltage value. This analog
*
par. 6-21 V]
input scaling value should correspond to
the minimum reference value set in
parameter 3-02 Minimum Reference. See
also chapter 3.4 Parameters: 3-** Reference/
Ramps.
6-21 Terminal 54 High Voltage
Range:
Function:
10 V
[ par. 6-20
Enter the high voltage value. This analog
*
- 10 V]
input scaling value should correspond to the
high reference feedback value set in
parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
6-22 Terminal 54 Low Current
Range:
Function:
0.14
[0.00 -
Enter the low current value. This reference
mA
par. 6-23
signal should correspond to the minimum
*
mA]
reference value, set in
parameter 3-02 Minimum Reference. Enter the
value that exceeds 2 mA to activate the live
zero timeout function in parameter 6-01 Live
Zero Timeout Function.
6-23 Terminal 54 High Current
Range:
Function:
20 mA
[ par. 6-22
Enter the high current value
*
- 20 mA]
corresponding to the high reference
feedback value set in
parameter 6-25 Terminal 54 High Ref./Feedb.
Value.
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0 ReferenceFeed-
[-999999.999 -
backUnit
999999.999
*
ReferenceFeed-
backUnit]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
1500.000
[-999999.999 -
ReferenceFeed-
999999.999
backUnit
*
Function:
Enter the analog input
scaling value that
corresponds to the
minimum reference
feedback value set in
parameter 3-02 Minimum
Reference.
Function:
Enter the analog input
scaling value that
113
3
3
