Parameter Descriptions
13-44 Logic Rule Boolean 3
Array [6]
Option:
3 3
[225] Position Limit
[226] Touch on Target
[227] Touch Activated
3.13.6 13-5* States
13-51 SL Controller Event
Option:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
160
®
VLT AutomationDrive FC 301/302
Function:
Error for the time set in
parameter 4-72 Position Error Timeout.
NOTICE
This option is available only with
software version 48.20 and
newer.
The position is outside the limits set
in parameter 3-06 Minimum Position
and parameter 3-07 Maximum Position.
NOTICE
This option is available only with
software version 48.20 and
newer.
Target position is reached in touch
probe position mode.
NOTICE
This option is available only with
software version 48.20 and
newer.
Touch probe positioning active. The
frequency converter monitors the
touch probe sensor input.
Function:
Select the boolean input (true or false)
to define the smart logic controller
event. See parameter 13-01 Start Event
(options [0] False–[61] Logic rule 5) and
parameter 13-02 Stop Event (options
[70] SL Time-out 3–[74] SL Time-out 7)
for more information.
Danfoss A/S © 01/2018 All rights reserved.
13-51 SL Controller Event
Option: Function:
[11] Below speed low
[12] Above speed high
[13] Out of feedb.
range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on the
graphical LCP.
[44] Reset key [Reset] is pressed. Only available on
the graphical LCP.
[45] Left key [◄] is pressed. Only available on the
graphical LCP.
[46] Right key [►] is pressed. Only available on the
graphical LCP.
▲
[47] Up key
[ ] is pressed. Only available on the
graphical LCP.
▼
[48] Down key
[ ] is pressed. Only available on the
graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
