Danfoss VLT AutomationDrive FC 301 Programming Manual page 29

Parameter Descriptions
0-20 Display Line 1.1 Small
Option: Function:
[1605] Main Actual Value Actual value as a percentage.
[%]
[1606] Actual Position Actual position in position units
selected in parameter 17-70 Position
Unit.
[1607] Target Position Active target position in position
units selected in
parameter 17-70 Position Unit.
[1608] Position Error Actual position PI error in position
units selected in
parameter 17-70 Position Unit.
[1609] Custom Readout
[1610] Power [kW] Actual power consumed by the
motor in kW.
[1611] Power [hp] Actual power consumed by the
motor in hp.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, that is the output
frequency from the frequency
converter in Hz.
[1614] Motor current Phase current of the motor
measured as effective value.
[1615] Frequency [%] Motor frequency, that is the output
frequency from the frequency
converter in percent.
[1616] Torque [Nm] Actual motor torque in Nm.
[1617] Speed [RPM] Speed in RPM (revolutions per
minute), that is the motor shaft
*
speed in closed loop.
[1618] Motor Thermal Thermal load on the motor,
calculated by the ETR function.
[1619] KTY sensor
temperature
[1620] Motor Angle
[1621] Torque [%] High
Res.
[1622] Torque [%] Present motor load as a percentage
of the rated motor torque.
[1623] Motor Shaft Power
[kW]
[1624] Calibrated Stator
Resistance
[1625] Torque [Nm] High
[1630] DC Link Voltage DC-link voltage in the frequency
converter.
[1632] Brake Energy /s Present brake power transferred to
an external brake resistor.
Stated as an instant value.
MG33MO02
Programming Guide
0-20 Display Line 1.1 Small
Option:
[1633]
[1634]
[1635]
[1636]
[1637]
[1638]
[1639]
[1644]
[1645]
[1646]
[1647]
[1648]
[1650]
[1651]
[1652]
[1653]
[1657]
[1660]
[1661]
[1662]
[1663]
Danfoss A/S © 01/2018 All rights reserved.
Function:
Brake Energy Brake power transferred to an
Average external brake resistor. The mean
power is calculated continuously for
the most recent 120 s.
Heatsink Temp. Present heat sink temperature of
the frequency converter. The cutout
limit is 95 ±5 °C (203 ±9 °F);
cutting back in occurs at 70 ±5 °C
(203 ±9 °F).
Inverter Thermal Percentage load of the inverters.
Inv. Nom. Current Nominal current of the frequency
converter.
Inv. Max. Current Maximum current of the frequency
converter.
SL Controller State State of the event executed by the
control.
Control Card Temp. Temperature of the control card.
Speed Error [RPM]
Motor Phase U
Current
Motor Phase V
Current
Motor Phase W
Current
Speed Ref. After
Ramp [RPM]
External Reference Sum of the external reference as a
percentage, that is the sum of
analog/pulse/bus.
Pulse Reference Frequency in Hz connected to the
digital inputs (18, 19 or 32, 33).
Feedback[Unit] Reference value from programmed
digital inputs.
Digi Pot Reference
Feedback [RPM]
Digital Input Signal states from the 6 digital
terminals (18, 19, 27, 29, 32, and
33). There are 16 bits in total, but
only 6 of them are used. Input 18
corresponds to the far left of the
used bits. Signal low = 0; Signal
high = 1.
Terminal 53 Switch Setting of input terminal 54.
Setting Current = 0; Voltage = 1.
Analog Input 53 Actual value at input 53 either as a
reference or protection value.
Terminal 54 Switch Setting of input terminal 54.
Setting Current = 0; Voltage = 1.
