Danfoss VLT AutomationDrive FC 301 Programming Manual page 32

Parameter Descriptions
0-30 Unit for User-defined Readout
Option:
[25] m³/h
[30] kg/s
[31] kg/min
3 3
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
0-31 Min Value of User-defined Readout
Range:
0.00 Custom-
ReadoutUnit
*
30
VLT
Function:
Function:
[-999999.99 - This parameter sets the
par. 0-32 minimum value of the custom-
CustomRea- defined readout (occurs at 0
doutUnit] speed). Only possible to set
different from 0 when selecting
a linear unit in
parameter 0-30 Unit for User-
defined Readout. For quadratic
and cubic units, the minimum
value is 0.
Danfoss A/S © 01/2018 All rights reserved.
®
AutomationDrive FC 301/302
0-32 Custom Readout Max Value
Range:
100 Custom-
ReadoutUnit
0-33 Source for User-defined Readout
Option:
[105] Torq relate to rated
[240] Default Source
*
0-37 Display Text 1
Range:
0 [0 -
*
25]
0-38 Display Text 2
Range:
0 [0 -
*
25]
0-39 Display Text 3
Range:
0 [0 -
*
25]
Function:
[ par. 0-31 - This parameter sets the
999999.99 maximum value to be shown
*
CustomRea- when the speed of the motor
doutUnit] has reached the set value for
parameter 4-13 Motor Speed High
Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
Function:
Enter the source of the user-defined
readout.
Function:
Enter a text which can be viewed in the graphical
display by selecting [37] Display Text 1 in
•
Parameter 0-20 Display Line 1.1 Small,
•
Parameter 0-21 Display Line 1.2 Small,
•
Parameter 0-22 Display Line 1.3 Small,
•
Parameter 0-23 Display Line 2 Large, or
•
Parameter 0-24 Display Line 3 Large.
Function:
Enter a text which can be viewed in the graphical
display by selecting [38] Display Text 2 in
•
Parameter 0-20 Display Line 1.1 Small,
•
Parameter 0-21 Display Line 1.2 Small,
•
Parameter 0-22 Display Line 1.3 Small,
•
Parameter 0-23 Display Line 2 Large, or
•
Parameter 0-24 Display Line 3 Large.
Function:
Enter a text which can be viewed in the graphical
display by selecting [39] Display Text 3 in
•
Parameter 0-20 Display Line 1.1 Small,
•
Parameter 0-21 Display Line 1.2 Small,
•
Parameter 0-22 Display Line 1.3 Small,
•
Parameter 0-23 Display Line 2 Large, or
•
Parameter 0-24 Display Line 3 Large.
