Parameter Descriptions
6-53 Terminal 42 Output Bus Control
Range: Function:
0 % [0 - 100 %] Holds the level of output 42 if controlled by
*
bus.
6-54 Terminal 42 Output Timeout Preset
Range: Function:
0 % [0 - Holds the preset level of output 42.
*
100 %] If a timeout function is selected in
parameter 6-50 Terminal 42 Output, the output
is preset to this level if a fieldbus timeout
occurs.
6-55 Analog Output Filter
Option: Function:
The following readout parameters from selection in
parameter 6-50 Terminal 42 Output have a filter
selected when parameter 6-55 Analog Output Filter is
on:
Selection
Motor current (0–I
max
Torque limit (0–T )
lim
Rated torque (0–T
nom
Power (0–P )
nom
Speed (0–Speed )
max
Table 3.23 Readout Parameters
[0] Off Filter off.
*
[1] On Filter on.
3.7.7 6-6* Analog Output 2 MCB 101
Analog outputs are current outputs: 0/4–20 mA. Common
terminal (terminal X30/8) is the same terminal and
electrical potential for analog common connection.
Resolution on analog output is 12 bit.
6-60 Terminal X30/8 Output
Option: Function:
Select the function of terminal X30/8 as an
analog current output. Depending on the
selection, the output is either a 0–20 mA or
4–20 mA output. The current value can be
read out in the LCP in
parameter 16-65 Analog Output 42 [mA].
[0] No When no signal on the analog output is
operation present.
[52] MCO
0-20mA
[100] Output 0 Hz = 0 mA; 100 Hz = 20 mA.
frequency
[101] Reference Parameter 3-00 Reference Range [Min. - Max.]
0% = 0 mA; 100% = 20 mA.
MG33MO02
Programming Guide
0–20 mA 4–20 mA
) [103] [133]
[104] [134]
) [105] [135]
[106] [136]
[107] [137]
Danfoss A/S © 01/2018 All rights reserved.
6-60 Terminal X30/8 Output
Option: Function:
Parameter 3-00 Reference Range [-Max. -
Max.] -100% = 0 mA; 0% = 10 mA; +100% =
20 mA
[102] Feedback
[103] Motor The value is taken from parameter 16-37 Inv.
Current Max. Current. The inverter maximum current
(160% current) is equal to 20 mA.
Example: Inverter normal current (11 kW) =
24 A. 160% = 38.4 A. Motor normal current
= 22 A, readout is 11.46 mA.
20 mA x 22 A
= 11 . 46 mA
38 . 4 A
In case the normal motor current is equal to
20 mA, the output setting of
parameter 6-62 Terminal X30/8 Max. Scale is:
I x 100
VLT
Max. =
I
Motor
Norm
[104] Torque rel to The torque setting is related to the setting
limit in parameter 4-16 Torque Limit Motor Mode.
[105] Torq relate The torque is related to the motor torque
to rated setting.
[106] Power Taken from parameter 1-20 Motor Power [kW].
[107] Speed Taken from parameter 3-03 Maximum
Reference. 20 mA = value in
parameter 3-03 Maximum Reference.
[108] Torque Torque reference related to 160% torque.
[109] Max Out In relation to parameter 4-19 Max Output
Freq Frequency.
[113] PID Clamped
Output
[119] Torque %
lim
[130] Output freq. 0 Hz = 4 mA, 100 Hz = 20 mA.
4-20mA
[131] Reference Parameter 3-00 Reference Range [Min.-Max.]
4-20mA 0% = 4 mA; 100% = 20 mA.
Parameter 3-00 Reference Range [-Max-Max.]
-100% = 4 mA; 0% = 12 mA; +100% = 20
mA.
[132] Feedback
4-20mA
[133] Motor cur. The value is taken from parameter 16-37 Inv.
4-20mA Max. Current. The inverter maximum current
(160% current) is equal to 20 mA.
Example: Inverter normal current (11 kW) =
24 A. 160% = 38.4 A. Motor normal current
= 22 A Readout 11.46 mA.
16 mA x 22 A
= 9 . 17 mA
38 . 4 A
In case the normal motor current is equal to
20 mA, the output setting of
parameter 6-62 Terminal X30/8 Max. Scale is:
I x 100
VLT
Max. =
I
Motor
Norm
[134] Torq.% lim The torque setting is related to the setting
4-20 mA in parameter 4-16 Torque Limit Motor Mode.
38 . 4 x 100
= 175 %
22
38 . 4 x 100
= 175 %
22
