Parameter Descriptions
3.15.7 15-2* Historic Log
View up to 50 logged data items via the array parameters
in this parameter group. Data is logged every time an
event occurs (not to be confused with SLC events). Events
in this context are defined as a change in 1 of the
following areas:
•
Digital inputs.
•
Digital outputs.
•
Warning word.
•
Alarm word.
•
Status word.
•
Control word.
•
Extended status word.
Events are logged with value and time stamp in ms. The
time interval between 2 events depends on how often
events occur (maximum once every scan time). Data
logging is continuous, but if an alarm occurs, the log is
saved and the values can be viewed on the display. This
feature is useful, for example when carrying out service
following a trip. View the historic log contained in this
parameter via the serial communication port or via the
display.
15-20 Historic Log: Event
Array [50]
Range: Function:
0 [0 - 255 ] View the event type of the logged events.
*
15-21 Historic Log: Value
Array [50]
Range: Function:
0 [0 - View the value of the logged event.
*
2147483647 ] Interpret the event values according to
Table 3.30:
Digital input
Digital output
(not
monitored in
this SW
release)
Warning word Decimal value. See
Alarm word
MG33MO02
Programming Guide
Decimal value. See
parameter 16-60 Digital
Input for description after
converting to binary
value.
Decimal value. See
parameter 16-66 Digital
Output [bin] for a
description after
converting to binary
value.
parameter 16-92 Warning
Word for a description.
Decimal value. See
parameter 16-90 Alarm
Word for a description.
Danfoss A/S © 01/2018 All rights reserved.
15-21 Historic Log: Value
Array [50]
Range: Function:
Status word
Control word
Extended
status word
Table 3.30 Logged Events
15-22 Historic Log: Time
Array [50]
Range: Function:
0 ms [0 - 2147483647 View the time at which the logged
*
ms] event occurred. Time is measured in
ms since frequency converter start. The
maximum value corresponds to
approximately 24 days, which means
that the count restarts at 0 after this
time period.
3.15.8 15-3* Alarm Log
Parameters in this group are array parameters where up to
10 fault logs can be viewed. 0 is the most recent logged
data, and 9 is the oldest. Fault codes, values, and time
stamp can be viewed for all logged data.
15-30 Fault Log: Error Code
Range: Function:
0 N/A [0 - 255 N/A] View the fault code and look up its
*
meaning in chapter 6 Troubleshooting.
15-31 Alarm Log: Value
Array [10]
Range: Function:
0 [-32767 - 32767 ] View an extra description of the error.
*
This parameter is mostly used in
combination with alarm 38, internal fault.
15-32 Alarm Log: Time
Array [10]
Range: Function:
0 s [0 - 2147483647 s] View the time when the logged event
*
occurred. Time is measured in s from
frequency converter start-up.
Decimal value. See
parameter 16-03 Status
Word for a description
after converting to binary
value.
Decimal value. See
parameter 16-00 Control
Word for a description.
Decimal value. See
parameter 16-94 Ext. Status
Word for a description.
