Parameter Lists
5.3.4 3-** Reference / Ramps
Par- Parameter description
ameter #
3-0* Reference Limits
3-00 Reference Range
3-01 Reference/Feedback Unit
3-02 Minimum Reference
3-03 Maximum Reference
3-04 Reference Function
5 5
3-05 On Reference Window
3-06 Minimum Position
3-07 Maximum Position
3-08 On Target Window
3-09 On Target Time
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-12 Catch up/slow Down Value
3-13 Reference Site
3-14 Preset Relative Reference
3-15 Reference Resource 1
3-16 Reference Resource 2
3-17 Reference Resource 3
3-18 Relative Scaling Reference Resource
3-19 Jog Speed [RPM]
3-2* References II
3-20 Preset Target
3-21 Touch Target
3-22 Master Scale Numerator
3-23 Master Scale Denominator
3-24 Master Lowpass Filter Time
3-25 Master Bus Resolution
3-26 Master Offset
3-27 Virtual Master Max Ref
3-28 Master Offset Speed Ref
3-4* Ramp 1
3-40 Ramp 1 Type
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-45 Ramp 1 S-ramp Ratio at Accel. Start
3-46 Ramp 1 S-ramp Ratio at Accel. End
3-47 Ramp 1 S-ramp Ratio at Decel. Start
3-48 Ramp 1 S-ramp Ratio at Decel. End
3-5* Ramp 2
3-50 Ramp 2 Type
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-55 Ramp 2 S-ramp Ratio at Accel. Start
3-56 Ramp 2 S-ramp Ratio at Accel. End
260
®
VLT AutomationDrive FC 301/302
Default value
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Sum
ExpressionLimit
-100000 CustomRea-
doutUnit2
100000 CustomRea-
doutUnit2
5 CustomReadoutUnit2
1 ms
0 %
ExpressionLimit
0 %
[0] Linked to Hand /
Auto
0 %
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] No function
ExpressionLimit
0 CustomReadoutUnit2
0 CustomReadoutUnit2
1 N/A
1 N/A
20 ms
65536 N/A
0 CustomReadoutUnit2
50.0 Hz
1500 RPM
[0] Linear
ExpressionLimit
ExpressionLimit
50 %
50 %
50 %
50 %
[0] Linear
ExpressionLimit
ExpressionLimit
50 %
50 %
