The Corpus Window
The System 3 devices that are supported by Corpus are listed below.
Device Name
RZ2/RZ5x
RZ6
PZn
UDP
RS4/PO8e
IZ2
RV2
RXn
RP2.1
RA16BA
Most DSP components have been implemented, however some components are either
not appropriate for emulation or are not yet supported. If an unsupported RPvdsEx
component is detected, the Status Indicator will turn red. Clicking on the indicator will
show a debug window that lists the offending component(s).
Inputting Fake Data
Corpus allows you to load data files onto the emulated hardware and play them out,
sample for sample, as if they can in on the actual hardware inputs.
A complete list of accepted file extensions and their associated hardware devices is
shown in table 2.
Hardware Component File Prefix
RZn
RZn
RZn
PZn
PZn
Corpus System 3 Hardware Emulator
Corpus Main Window
Corpus Emulation Support
Fully supported, but some hardware features not simulated or emulated
Fully supported, excluding audio features
Can generate simulated neural signals, but not all device features fully
emulated
Fully simulated, packets will be sent and received via host computer's
Ethernet port
Device is recognized but cannot be emulated
Device is recognized but cannot be emulated
Device is recognized but cannot be emulated
Device is not supported by Corpus
Device is not supported by Corpus
Device is not supported by Corpus
ADC adc mat, wav
ADC adcN mat, wav, f32, i32, i16, txt
Digital I/O Bits mat, wav, f32, i32, i16, txt
PZ chan mat
PZ chanN mat, f32, txt
File Extension
System 3
