System 3
The Indicator Light
A front panel switch turns on the chassis power supply and includes an indicator
light. The power switch's green LED will illuminate when the chassis is switched on.
The light will flash rapidly when it receives a command from software and slowly to
indicate a communications error (check all cable connections).
Disconnecting Power from the Chassis
CAUTION! When removing the power cord from either the power supply or
socket outlet, grasp the plug, not the cord, in order to avoid damaging the cable.
To disconnect the ZB1PS:
1.
2. Disconnect the power cord from the power supply.
3. Disconnect the power cord from the wall socket plug.
Adding and Removing Modules
Before adding or removing modules, make sure the zBus is powered off.
To remove a module from the chassis:
1.
2. Pull straight out on the front-panel BNC connectors. A BNC 'T' connector
To add a module to a chassis:
1.
2. Hold the module in place with the thumb screws.
Turn off the power switch.
Unscrew the two thumb screws on the corner of the module faceplate.
makes a great handle for removing zBus devices.
Insert the module into an empty bay and push straight back until it seats
onto the connector.
ZB1PS - Powered zBus Device Chassis
20-5
