- Page 1 PP24 Patch Panel Hardware Reference Updated 2021-09-15...
- Page 2 The information contained in this document is provided "as is," and is subject to being changed, without notice. TDT shall not be liable for errors or damages in connection with the furnishing, use, or performance of this document or of any information contained herein.
-
Page 3: Table Of Contents
Table of Contents | 3 Table of Contents PP24 Patch Panel Overview Adjustable Positioning Mapping the Inputs and Outputs for Each Device RZ5, RZ5D, RZ5P, RZ6, RZ10x Digital I/O RZ2 Digital I/O RX5 or RX7 I/O RX6 Digital I/O RX8 I/O... -
Page 4: Pp24 Patch Panel
PP24 to an RX device positioned either directly above or directly below the PP24. The RZ CONN connects an RZ processor positioned above the PP24. Loosen the four thumbscrews (one on each corner of the PP24 front panel) to slide the BNC array into the correct position to align the connector with the target device. -
Page 5: Mapping The Inputs And Outputs For Each Device
Mapping the Inputs and Outputs for Each Device The PP24 consists of 3 banks of BNC connectors, Bank A, B, and C. Each of the banks is labeled 1-8 within the set and each BNC is also numbered as part of the entire group from 1 - The following table shows the configuration of the BNC connectors for each I/O connector of the RX and RZ devices. -
Page 6: Rz5, Rz5D, Rz5P, Rz6, Rz10X Digital I/O
Port B Bits 0-7 RZ2 Digital I/O The PP24 is mounted below the RZ2. Ports A & C are available on the RZ2 front panel BNCs. Port B is only accessible through the DB25 connector. RZ2 Digital I/O connection to the PP24... -
Page 7: Rx5 Or Rx7 I/O
Port C Bits 0-7 Port A Bits 0-7 Port B Bits 0-7 RX5 or RX7 I/O The PP24 can be mounted above or below the RX5. RX5 and RX7 Digital I/O connections to the PP24 A1 - A8 B1 - B8... -
Page 8: Rx6 Digital I/O
PP24 Patch Panel | 8 RX6 Digital I/O The PP24 can be mounted above or below the RX6. RX6 Digital I/O connection to the PP24 A1 - A8 B1 - B8 C1 - C8 Bit Addressable Digital I/O Digital I/O... - Page 9 PP24 Patch Panel | 9 RX8 Analog I/O connection to the PP24 A1 - A8 B1 - B8 C1 - C8 Analog I/O Block A Analog I/O Block B Analog Output Block C Channels 1-8 Channels 9-16 Channels 17-24...
