TDT RZ2 Manual page 511

System 3
Note: There are 16 channels per DB26 connector. Bank A is shown. Channels in Bank B
are incremented by an additional 16 channels.
Pin
1 A1
2 A2
3 A3
4 A4
5 Ref
6 NA
7 A5
8 A7
9 A9
10 A11
11 A13
12 A15
13 GND
Name Description
Analog Output Channels
Reference
Not Used
Analog Output Channels
Ground
Pin Name Description
14 NA Not Used
15 GND Ground
16 NA Not Used
17 NA
18 NA
19 NA
20 A6 Analog Output Channels
21 A8
22 A10
23 A12
24 A14
25 A16
26 NA Not Used
