7-50
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
Note: Channels 5 - 16 not available on the MS4.
Control Output Connector
This connector provides access to control or relay output channels.
MS4/MS16 Stimulus Isolator
Name Description
A1 Analog Channels
Ch 1-4
A2
A3
A4
Ref Reference
NA Not Used
A5 Analog Channels
Ch 5, 7, 9, 11, 13,
A7
and 15
A9
A11
A13
A15
NA Not Used
Pin Name Description
14 NA Not Used
15
16
17
18
19
20 A6 Analog Channels
Ch 6, 8, 10, 12,
21 A8
and 14, 16
22 A10
23 A12
24 A14
25 A16
System 3
