TDT RZ2 Manual page 448

10-34
Technical Specifications
connected to a single common node. See "Headstage Connection Guide" on
page 6-93, for more information.
Input Referred Noise
Headstage Gain
Input Impedance
Pinout Diagram
The numbers in the diagram above show the channel connections to the amplifier.
The headstage also features jumper locations to short G, R and Ref refers to the
built-in reference site on the NeuroNexus probe). The ground channel (G) should
either be tied to an external ground or to the reference (R) for a single ended
input.
Important! When using the NN64AC with the NeuroNexus Acute 64-channel probe, keep in
mind that there are several versions of the probe. Check the NeuroNexus Website for
pin diagrams. Also, see "MCMap" in the
examples on how to re-map channel numbers.
Jumper Configuration
The following table describes the jumper configurations and associated requirements.
Jumper Connections
G
R
Ref
Acute (Non-ZIF) Headstages
WARNING! When using multiple headstages ensure that all ground pins are
rms 3 μV bandwidth 300-3000 Hz
rms 6 μV bandwidth 30-8000 Hz
Unity (1x)
10
14
(looking into connections)
Shorts headstage Ground and Reference
inputs together, yielding single-ended
amplification of signals relative to
ground.
Ohms
RPvdsEx Manual
Operation
System 3
, for a description and
Requirements
Connect common
Ground/Reference wire
to the headstage or
electrode.
