TDT RZ2 Manual page 385

System 3
Reboot System:
Device Status LEDs
The device status LEDs report streaming or network activity. The following tables
display the status LED indicators.
Video
Network
Storage
Ethernet Ports
Two Ethernet ports are provided on the back panel, Video and Network.
Camera-1
Network
Power Port
A 9-pin serial port is provided on the back panel, labeled Power. This port is
connected to a special cable that provides power to the VGAC using the special gray
cable provided with the system.
VGA Port
A VGA port is provided on the back panel, labeled Monitor. This port can be
connected to an external monitor that will show the current camera image or a video
that is being played in the Playback tab.
Important!: The external monitor must be connected before the RV2 is powered on.
USB 2.0 Port
This port is currently not in use.
Click to reboot the system.
Status Information
Off No video camera is detected.
Lit Video camera has been found
Status Information
Off No network traffic detected.
Lit Network traffic is present and detected on the RV2.
Status Information
Off No storage access to the RV2 is detected.
Lit Storage access to the RV2 is in progress
The Camera-1 port connects directly to the Ethernet port on the
VGAC. Important! The cable connecting the RV2 to the VGAC
MUST support gigabit Ethernet (e.g. Cat 5e, Cat 6).
The Network port allows connections to either a PC or local
area network via a standard Ethernet cable. The RV2 supports
automatic DHCP protocol.
8-17
RV2 Video Processor
