TDT RZ2 Manual page 482

11-8
Pinout Diagram
Note: Pins 1, 21-24 and 39 are not connected.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Low Impedance Headstages
Name Description
NA Not Used
A2 Analog Input
D3 Differential Input
D5
A5 Analog Input
A7
A8
A9
D9 Differential Input
A10 Analog Input
A11
A12
D13 Differential Input
AGND Analog Ground
A16 Analog Input
A1
D2 Differential Input
A4 Analog Input
AGND Analog Ground
A6 Analog Input
NA Not Used
NA
NA
NA
Pin Name Description
25 AGND Analog Ground
26 AGND
27 D12 Differential Input
28 A14 Analog Input
29 A15
30 D16 Differential Input
31 D1
32 A3 Analog Input
33 D4 Differential Input
34 AGND Analog Ground
35 D6 Differential Input
36 D7
37 D8
38 AGND Analog Ground
39 NC
40 D10 Differential Input
41 D11
42 A13 Analog Input
43 D14 Differential Input
44 D15
