TDT RZ2 Manual page 32

1-26
DB25 Analog I/O Pinout
Pin
1 NA
2
3
4
5 AGND
6 A2
7 A4
8 NA
9 NA
10 A10
11 A12
12 NA
13 NA
DB25 Digital I/O Pinout
Byte B
Pin Name
1 C0
2 C2
3 C4
4 C6
5 GND
6 A1
7 A3
8 A5
9 A7
10 B1
11 B3
12 B5
13 B7
RZ5D BioAmp Processor
Analog Out
Name Description
Not Used
Analog Ground
ADC
Analog Input Channels
Not Used
DAC
Analog Output Channels
Not Used
Byte A
Description
Byte C
Bit Addressable
Digital I/O
Bits 0, 2, 4, and 6
Digital I/O Ground
Byte A
Word Addressable
Digital I/O
Bits 1, 3, 5 and 7
Byte B
Word Addressable
Digital I/O
Bits 1, 3, 5 and 7
Analog Out AGND
Pin Name
14 NA
15
16
17
18 A1
19 A3
20 NA
21 NA
22 A9
23 A11
24 NA
25 NA
GND
Pin Name
14 C1 Byte C
Bit Addressable
15 C3
Digital I/O
16 C5
Bits 1, 3, 5, and 7
17 C7
18 A0 Byte A
Word Addressable
19 A2
Digital I/O
20 A4
Bits 0, 2, 4 and 6
21 A4
22 B0 Byte B
Word Addressable
23 B2
Digital I/O
24 B4
Bits 0, 2, 4 and 6
25 B6
System 3
Description
Not Used
ADC
Analog Input Channels
Not Used
DAC
Analog Output Channels
Not Used
Byte C
Description
