Mapping the Inputs and Outputs for Each Device
Each device has a unique input and output configuration. The table below shows the
configuration of the BNC connectors.
Device & Connector
RP2, RP2.1
Digital I/O
Connector
RA16BA
Analog/Digital I/O
Connector
RV8, RV8D
Digital I/O
Connector
RV8D*
Optional I/O
Connector
RA8GA
Analog I/O
Connector
PM2R
Signal Out
Connector
SA8
Power Outputs
Connector
*To use the RV8D Optional I/O analog output connector, move all the DIP switch
positions to the OFF setting on the PP16. Once the switches are in this position
digital inputs 8-15 are not accessible. Do NOT attempt to output analog signals
when the switches are in the ON position.
PP16 Patch Panel
A1-A8
Digital Inputs Digital Outputs
Channels 1-8 Channels 1-8
Analog Outputs Digital Outputs
Channels 1-8 Channels 0-7
Digital Inputs Digital Outputs
Channels 8-15 Channels 0-7
Analog Outputs Not Used
Channels 1-8
Analog Input Not Used
Channels 1-8
Analog Output Analog Output
Channels 0-7 Channels 8-15
Analog Output Analog Output
Channels 1-8 Signal and Ground:
Channels 1-4
B1-B8 C1-C8
C1=Trigger
C2=Volt out (3.3v)
Digital Outputs
Channels 8-15
Digital Inputs
Channels 0-7
Not Used
Not Used
Not Used
Analog Output
Signal and Ground:
Channels 5-8
