System 3
When using the LZ48 battery pack, the IZ2 uses the V
and V
B
The LZ48M battery pack is a single battery bank that drives both the logic control
and the waveform output, and includes additional over-current fault protection. IZ2
and IZ2H devices manufactured before 07/13/2017 require a firmware update to
operate with LZ48M batteries.
The number of channels needed for stimulation determines power requirements. The
IZ2-128 and IZ2H-16 should only be used with the LZ48-400 or LZ48M-500. The
IZ2-32 and IZ2-64 can be used with any LZ battery.
See "LZ48 Battery Reference" on page 7-17, for technical specifications and for
more information.
Hardware Set‐up
The IZ2 Connection and Boot Procedure
1.
2. Connect the stimulator to the base station using the provided fiber optic
3. Power on the RZ base station.
4. Verify that the subject is NOT connected to the IZ2 stimulator.
5. Verify that the LZ48 battery is off and connect the battery pack cable to the
batteries are used to drive the positive and negative stimulation waveforms.
Ensure that the TDT drivers, PC interface, RZ and zBus devices are
installed, setup, and configured according to the installation guide provided
with your system.
cable. If using an RZ2 or RZ6 base station, connect the fiber optic cable
from the IZ2 fiber optic port labeled 'Fiber' to the fiber optic port labeled
'To IZ2' on the back side of the RZ. If using an RZ5D base station,
connect the fiber to the 'IZ' port on the front of the RZ5D. Be sure to note
the difference in the two sides of the fiber optic cable connectors and ensure
they are inserted with the correct side up.
back panel of the stimulator via the connector labeled Battery, as shown in
the diagram below.
battery for logic control. V
C
IZ2/IZ2H Stimulator
7-5
