17-4
Button Number:
0
1
2
3
Note that the logic on the inputs to the RP/RM/RX processors is reversed.
Therefore, when polling the lines to determine if a button has been pressed, a logic
high or '1' means that no button is pressed and a logic low or '0' indicates a
button press.
Contact TDT for assistance with custom button or LED configurations.
Configuring an RM Processor for the RBOX4
The RBOX4 uses the ground connection (pin 1) and the 8 bits of digital I/O on
an RM-series processor Digital I/O port. Bits 0 through 3 are used as button inputs
and Bits 4 through 7 are used as LED outputs.
To use the response box with an RM processor, configure the bits in the
RPvdsEx configuration register as follows:
1.
2. In the Set Hardware Parameters dialog box, click the Type drop-down
3. The dialog expands to display the Edit Bit Dir Control dialog box.
4. Click Modify to display the Edit Bit Dir Control dialog box. In this dialog
RBOX Response Box
BitIn Mask Value:
M=1
M=2
M=4
M=8
Click the Device Setup command on the Implement menu.
box and select either the RM1 or RM2 from the list.
box, a series of check boxes are used to create a bitmask that is used to
program all bits.
LED Number:
BitOut Mask Value:
4
M=16
5
M=32
6
M=64
7
M=128
System 3
