16-40
CF1 Technical Specifications
Crossover Frequency
Weight
Dimensions
Typical Output (+/- 1 V peak
input)
THD
Closed‐field Frequency Response
CF1 measurements typical for approx 0.1cc pvc tube coupler using +/‐ 1V input.
CF1/FF1 Magnetic Speakers
500 Hz High Pass
~590 Grams
7.62 cm outside diameter x 8.89 cm deep
120 dB SPL from 1 kHz to 40 kHz
<= 1% from 1kHz to 40 kHz
System 3
