TDT RZ2 Manual page 251

System 3
Amp Type Selection Screen
The Amp Type Selection screen is displayed by touching the
the Main Configuration screen or by touching the
the Configuration Options screen for an existing logical amplifier.
On the Amp Type Selection screen, users can set the number of channels in a
logical amplifier or touch a configuration icon on the left side of the screen to select
one of four amp types, each with configuration presets displayed to the right. These
configuration options can be changed after the Amp Type is selected.
SU
Not configured
Warning: A red outline indicates the bank is configured as
part of a logical amplifier but no headstage is currently
detected on that bank.
Teal
Gray
Plus Sign icon on
Amp Type button on
