TDT RZ2 Manual page 518

12-36
Pinout Diagrams
(1‐32) DB37 Connector
Ground
Reference
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Note: No connections should be made to pins 17, 18, and 36.
(33‐64) DB37 Connector
Increment above channel numbers by 32.
Electrodes Mini‐DB80
The pinout for this connector duplicates the map of the PZ5M Input Connectors and
is dependent on the NeuroDigitizer reference mode. See the PZ5M "Input
Connectors" on page 6-53.
Preamplifier Adapters
Name Description
A1 Analog input
channels
A3
1,3,5,7,9,11,13,1
5,17,19,21,23,25
A5
,27,29,31
A7
A9
A11
A13
A15
A17
A19
A21
A23
A25
A27
A29
A31
NA Not Used
NA
GND Ground
Analog Channels
Pin Name Description
20 A2 Analog input
channels
21 A4
2,4,6,8,10,12,14,
16,18,20,22,24,2
22 A6
6,28,30,32
23 A8
24 A10
25 A12
26 A14
27 A16
28 A18
29 A20
30 A22
31 A24
32 A26
33 A28
34 A30
35 A32
36 NA Not Used
37 REF Reference
System 3
