TDT RZ2 Manual page 66

1-60
DB25 Analog I/O Pinout
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
RZ5 BioAmp Processor
Analog Out Analog Out
Name Description
NA Not Used
AGND Analog Ground
A2 ADC
Analog Input Channels
A4
NA
NA
A10 DAC
Analog Output Channels
A12
NA
NA
Maps to:
Ch 1-4 Analog In
Ch 9-12 Analog Out
Port C
Bits 0-3 Digital I/O
AGND
Pin Name Description
14 NA Not Used
15
16
17
18 A1 ADC
Analog Input Channels
19 A3
20 NA
21 NA
22 A9 DAC
Analog Output Channels
23 A11
24 NA
25 NA
System 3
