System 3
IZ2 Stimulator Technical Specifications
Includes specifications for the IZ2-32, IZ2-64, IZ2-128 and IZ2H-16.
Stimulus Output Channels
Sampling rate
Stimulus Output Voltage
Stimulus Output Current
Offset Current
ADC Filter
Power Control/Stimulation
Battery Life
^Note: the sampling rate is also limited by the RZ processor used for stimulator
control. When sampling at 195.3125 kHz, recording is limited to the first five
channels on each bank of channels.
Slew Rate for the IZ2H‐16
The slew rate is a measure of how quickly the output voltage of the device can
change. The plots below show the effect of the slew rate on a square wave
produced by the IZ2H at different loads and levels.
16 (IZ2H-16), 32 (IZ2-32), 64 (IZ2-64) or 128
(IZ2-128) PCM DACs
IZ2H-16: Up to 195.3125 kHz^
IZ2-32: Up to 195.3125 kHz^
IZ2-64: Up to 97.65625 kHz^
IZ2-128: Up to 48.828125 kHz^
+/- 12 V in voltage-controlled mode
IZ2: +/- 300 μA up to 50 kOhm load
IZ2H: +/- 3 mA up to 5 kOhm load
< 100 nA on active channels and < 3 nA on open
channels
Single pole 16kHz on voltage monitors
LZ48 or LZ48M Rechargeable Battery Pack with Li-Poly
batteries
LZ48-200 ~ 6-8 hours to charge
LZ48-400 ~ 12-14 hours to charge
Battery life between charges:
LZ48-200 w/ IZ2: 2 banks (up to 32 ch) ~ 20 hrs
4 banks (up to 64 ch) ~ 10 hrs
LZ48-400 w/ IZ2H: 1 bank (up to 8 ch) ~ 12 hrs
2 banks (up to 16 ch) ~ 6 hrs
LZ48-400 w/ IZ2: 2 banks (up to 32 ch) ~ 30 hrs
4 banks (up to 64 ch) ~ 20 hrs
8 banks (up to 128 ch) ~ 10 hrs
LZ48M-250 w/ IZ2: 2 banks (up to 32 ch) ~ 15hrs
LZ48M-250 w/ IZ2H: 2 banks (up to 16 ch) ~ 15hrs
LZ48M-500 w/ IZ2: 2 banks (up to 32 ch) ~ 30hrs
LZ48M-500 w/ IZ2H: 2 banks (up to 16 ch) ~ 30hrs
Note: The LZ48-200 is not recommended for use with
the IZ2-128 or the IZ2H-16
7-13
IZ2/IZ2H Stimulator
