TDT RZ2 Manual page 345

System 3
IZ2M/IZ2MH Stimulator Technical Specifications
Stimulus Output Channels
Sampling Rate
Stimulus Output Voltage
Stimulus Output Current
Offset Current
Battery
Mini‐DB26 Connector Pinouts for the IZ2M/IZ2MH
Stim Output Connector
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
Note: Contact TDT technical support (386-462-9622 or support@tdt.com)before attempting
to make any custom connections to pins 6, 18, or 19.
32 or 64
Up to 48.828125 kHz
+/- 12 V
IZ2M: +/- 300 μA up to 40 kOhm load
IZ2MH: +/- 3 mA up to 4 kOhm load
< 100 nA on active channels and < 3 nA on open channels
240 Wh
20 hours to fully charge
16-18 hours to charge to 95% capacity
7.5 hours between charges
Name Description
A1
Analog Output
A2
Channels
A3
A4
Reserved
HSD Headstage Detect
A5
A7
A9
Analog Output
Channels
A11
A13
A15
Reserved
Pin Name Description
14 Reserved
15 GND Ground
16 GND Ground
17 Reserved
18 HSD Headstage Detect
19 HSD
20 A6
21 A8
22 A10
Analog Output
Channels
23 A12
24 A14
25 A16
26 Reserved
IZ2M/IZ2MH Stimulator
7-31
