Window
The main workspace window displays an image from a camera or loaded file. Click-
and-drag tools are used to define regions and targets on a map overlaying the
image.
Menus and Toolbars
A comprehensive set of menus and toolbars provides access to commands and tools.
Frequently-used commands are available via toolbar buttons. Move the mouse pointer
over a toolbar button to display the button name. A tool tip for the button is also
displayed in the Status Bar. See "Menu and Toolbar Reference" on page 8-34, for
a complete list of commands and tools. Context sensitive menus are available by
right-clicking the workspace.
Status Bar
A status bar along the bottom of the window displays status messages, tool tips.
The right side of the status bar displays the coordinates of the pointer.
Creating a Configuration
Before a recording session can be started, an RVMap configuration file (*.rvm)
must be created, saved, and uploaded to the RV2. Configurations are created by
drawing regions and targets to create a map overlaying a reference image. The
*.rvm files contain region descriptions, reference points, target descriptions and
camera settings.
Loading an Image
RVMap can load a snapshot image from a connected RV2 and camera or from a
previously saved image file.
Loading Existing Image Files
To load an existing image:
1.
2. The Specify Image File dialog box is launched.
RVMap Software for RV2
Click the File menu and click Load Image.
or
Click the Load Image button on the Standard Toolbar.
Browse to the desired folder.
