TDT RZ2 Manual page 21

System 3
BNC Channel Mapping
Please note channel numbering begins at the top right block of BNCs for each port
and is printed on the face of the device to minimize miswiring. The figure below
represents the standard configuration and may vary depending on customer request.
DB25 Analog I/O Pinout
Analog Out
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
Analog In
Name Description
NA Not Used
AGND Analog Ground
A2 A
Analog Input
A4
Channels
A6
(Port D)
A8
A10 DAC
Analog Output
A12
Channels
A14
(Port E)
A16
AGND
Pin Name
14 NA Not Used
15
16
17
18 A1 A
Analog Input
19 A3
Channels
20 A5
(Port D)
21 A7
22 A9 DAC
Analog Output
23 A11
Channels
24 A13
(Port E)
25 A15
RZ2 BioAmp Processor
1-15
Description
