TDT RZ2 Manual page 690

18-32
J2 DB25 Pinout
Analog input channels 1-8.
Typically used to input
signals from the RA16BA or
the RV8.
Note: Female pin-in shown.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
J3 DB25 Pinout
Analog input channels 9-
16. Typically used to input
signals from the RA16BA.
Note: Female pin-in
shown.
Pin
1 A9
2 A11
3 A13
4 A15
5 GND
6 NA
7
8
9
10
11
12
13
ETM1 Experiment Test Module
Name Description
A1 Analog Input Channels
A3
A5
A7
GND Ground
NA Not Used
Name Description
Analog Input Channels
Ground
Not Used
Pin Name Description
14 A2 Analog Input Channels
15 A4
16 A6
17 A8
18 NA Not Used
19
20
21
22
23
24
25
Pin Name Description
14 A10 Analog Input Channels
15 A12
16 A14
17 A16
18 NA Not Used
19
20
21
22
23
24
25
System 3
