TDT RZ2 Manual page 300

6-92
Cross Talk
Input Impedance
Offset
Analog Input Pinout Diagram
Pin
1 A1
2 A3
3 A5
4 A7
5 AGND
6 NA
7
8
9
10
11
12
13
RA8GA Adjustable Gain PreAmp
6, 12, or 25 kHz
A/D Sample Rate
< -70 dB (DC - Nyquist)
10 kOhm
< 5 mV at +/- 10 V
< 3 mV at +/- 1 V and +/- 100 mV
Name Description
Analog Input Channels
Ground
Not Used
Pin Name Description
14 A2
15 A4
Analog Input Channels
16 A6
17 A8
18 NA
19
20
21
Not Used
22
23
24
25
System 3
