System 3
Pin Name
1 A1
2 A2
. .
. .
. .
31 A31
32 A32
33 HSD
34 HSD
35 NA
36 Refa
37 NA
38 NA
39 V+a
40 V-a
Shared Reference Mode
Pin
1 A1
2 A2
. .
. .
. .
31 A31
32 A32
33 HSD
34 HSD
35 NA
36 Refa
37 NA
38 Ga
39 +Va
40 -Va
Description
Analog Input Channels
(1-32)
Headstage Detect
Headstage Detect
Not Used
Reference
Not Used
Not Used
Positive Voltage
Negative Voltage
Name Description
Analog Input Channels
(1-32)
Headstage Detect
Headstage Detect
Not Used
Reference
Not Used
Ground
Positive Voltage
Negative Voltage
Pin Name Description
41 A33 Analog Input
Channels (33-64)
42 A34
. .
. .
. .
71 A63
72 A64
73 HSD Headstage Detect
74 HSD Headstage Detect
75 NA Not Used
76 Refb Reference
77 NA Not Used
78 NA Not Used
79 V+b Positive Voltage
80 V-b Negative Voltage
Pin Name Description
41 A33 Analog Input Channels
(33-64)
42 A34
. .
. .
. .
71 A63
72 A64
73 HSD Headstage Detect
74 HSD Headstage Detect
75 NA Not Used
76 Refb Reference
77 NA Not Used
78 Gb Ground
79 +Vb Positive Voltage
80 -Vb Negative Voltage
PZ5M Medically Isolated NeuroDigitizer
6-55
