TDT RZ2 Manual page 255

System 3
(see "Pinout Diagrams" on page 6-53. Ref and AltRef impedance values are
displayed on the top row. This is the default reference mode for the SU amp type.
Shared Reference Mode
If the reference mode is Shared, the options are
for the reference channel, and
impedance values are displayed on the top row. This is the default reference mode
for the EEG and LFP amp types.
None
If the reference mode is
System Setup Screen
The System Setup screen is displayed by touching the PZ5M logo on the top-left of
the Main Configuration screen.
Options include:
Config
Update
Wifi
Info
Done Button
Return to the Main Configuration window.
System Configure Screen
The System Configure screen is displayed by touching Config on the System Setup
screen.
Gnd
to test the ground impedance.
None
, the only option is Input for the input channels.
Open the System Configure screen.
Update onboard software over the Internet.
Connect to a wireless network for system updates.
Open the device System Info screen to view version
numbers for various hardware, software and firmware
components.
Input
for all the input channels,
Ref
PZ5M Medically Isolated NeuroDigitizer
6-47
Ref
Gnd
and
