TDT RZ2 Manual page 574

15-16
ACO Technical Specifications
Channels:
Signal/Noise:
RPM (approx):
Digital Inputs:
Power
Consumption:
Run time:
Power Supply:
Weight (g):
ACO32/ACO64 Motorized Commutators
ACO32: with PZ2 or PZ5: up to 32 analog channels
with PZ5: up to 256 digital channels
ACO64: with PZ2 or PZ5: up to 64 analog channels
with PZ5: up to 512 digital channels
AC16: 16
AC32: 32
AC64: 64
120 dB (20 Hz to 25 kHz)
18
1 Inhibit
ACO32 and ACO64 quiescent: 35 mA
ACO32 rotating: 65 mA
ACO64 rotating: 75 mA
ACO32: ~20 hr
ACO64: ~40 hr
ACO32: 1950 mAh Li-ion battery. 1000 cycles of charging.
ACO64: 3900 mAh Li-ion battery. 1000 cycles of charging.
Charger 6-9 V, 3A, center negative.
Battery charges in 3-4 hours.
ACO32 ~917
ACO32 with FORJ ~957
ACO64 ~1372
ACO64 with FORJ ~1412
AC16, AC32 ~665
AC64 ~945
System 3
