TDT RZ2 Manual page 632

17-14
[1:1,0]
PulseTrain2
nPer=60
nPulse=-1
Enab=Yes
Rst=Run
PLate=0
PCount=0
The PulseTrain2 component sends out a pulse every 60 samples. The output from
the PulseTrain2 is sent to the Trigger line on a latch. Therefore the output from the
latch is updated once every 60 samples. This generates an updated output that more
closely matches the data transfer rate of the motion tracker. The output can then be
sent to a head related transfer function (HRTF) coefficient generator (see "Using
the HTI3 with HRTF Filters" on page 17-15).
chan1
chan2
chan3
Another way to use the decimated signal would be to send it to a Serial Buffer
input. In this case the values are stored once every 60 samples. If you were using
this with OpenEx this would be the primary way to save the data set.
Azm1_Deg
decimate
Azimuth
Elv 1_Deg
decimate
Elevation
Roll1_Deg
decimate
HTI3 Head Tracker Interface
decimate
decimate
[1:9,0]
ScaleAdd
SF=180
Shft=0
[1:12,0]
ScaleAdd
SF=180
Shft=0
[1:6,0]
ScaleAdd
SF=180
Shft=0
[1:10,0]
SerStore
Size=1000
Rst=0
WrEnab=1
Index=0
{>Data}
[1:14,0]
SerStore
Size=1000
Rst=0
WrEnab=1
Index=0
{>Data}
[1:6,0]
SerStore
Size=1000
Rst=0
WrEnab=1
Index=0
Roll
{>Data}
[1:10,0]
Latch
Azm1_Deg
Trg=0
[1:13,0]
Latch
Elv 1_Deg
Trg=0
[1:7,0]
Latch
Roll1_Deg
Trg=0
Index
System 3
