Application Guide | iC2-Micro Frequency Converters
Table 41: Query
Field name
Follower address
Function
Starting address HI
Starting address LO
Number of points HI
Number of points LO
Error check (CRC)
Response
The register data in the response telegram is packed as 2 bytes per register, with the binary contents right justified within each byte. For
each register, the 1st byte contains the high-order bits, and the 2nd contains the low-order bits.
Example: hex 000088B8 = 35.000 = 35 Hz.
Table 42: Response
Field name
Follower address
Function
Byte count
Data HI (register 3030)
Data LO (register 3030)
Data HI (register 3031)
Data LO (register 3031)
Error check (CRC)
Force/Write Single Coil (05 hex)
6.1.7.6.3
Description
This function forces the coil to either ON or OFF. When broadcast, the function forces the same coil references in all attached followers.
Query
The query telegram specifies the coil 65 (parameter write control) to be forced. Coil addresses start at 0, that is, coil 65 is addressed as 64.
Force data = 00 00 hex (OFF) or FF 00 hex (ON).
92
| Danfoss A/S © 2024.03
Example (hex)
01
03 (Read holding registers)
0B (Register address 3029)
D5 (Register address 3029)
00
02 – (P 5.5.3.3 Reference Maximum is 32 bits long, that is, 2 regis-
ters)
Example (hex)
01
03
04
00
00
88
B8
AB413939445838en-000301 / 130R1254
