Parameter Descriptions

7

Reading the Parameter Table

7.1
The application guide includes the parameter tables. The following descriptions explain how to read the parameters.
1
P 2.1.1 DC-Link Voltage
2
View the DC Link voltage in the drive
3
Default value:
0
Parameter
1630
4
number:
5 Data type:
uint 32
Figure 69: Reading the Parameter Table
1 indicates the parameter name and parameter index, and starts with a P.
2 indicates the parameter description which is visible in MyDrive® Insight help text.
3 indicates the default setting from the factory.
4 indicates the unique parameter number which is relevant for modbus registers. See
Parameter Handling.
5 indicates the data type of the parameter. See
6 indicates the type of parameter. Parameters have either defined ranges or selections. See
7 indicates the unit of the parameter.
8 indicates the access type of the parameter. See

Understanding Parameter Types

7.1.1
Following are the different type of parameter information.
Table 60: Parameter Types and Description
Parameter Type Description
Selection The parameter provides a list of selections for the user to select.
Range (0–255) The value of the parameter is within the specified range. In the example specified, the user can set any value 0–
255, for the parameter.

Understanding Data Types

7.1.2
Following is an overview of the data types used in iC2 application software.
Table 61: Overview on data type
Data type
enum
int
Danfoss A/S © 2024.03
6
Parameter type:
7
Unit:
8 Access type:
7.1.2 Understanding Data
7.1.3 Understanding Access
Description
Enumeration
Integer
Range (0–65535)
V
Read
6.1.6.2.8 Parameter Number (PNU)
Types.
7.1.1 Understanding Parameter
Types.
Type
8, 16, 32
AB413939445838en-000301 / 130R1254 |
and 6.1.7.5.1
Types.
Range
0,1,2....
-32768...32767
