Application Software Structure and Overview

4

Understanding Application Software Structure

4.1
The basic design principle of the application software structure and the related hierarchy refers to the setup of a typical iC2-Micro drive,
as shown in the Figure 33.
6 Maintenance & Service
5 Application
3 Filters & Brake Chopper
1 Grid
2 Power
Conversion & DC-link
8 Customization
10 Connectivity
Figure 33: Application Menu Overview

Parameter Groups, Related Content, and Settings

4.2
All generic settings such as Grid, Power Conversion and DC-link, Filters & Brake Chopper, and Motor are accessed via parameter
l
groups (menu indexes) 1–4.
Most of the application-specific parameters are accessed via parameter groups (menu index) 5 Application.
l
Features and functions related to the application such as Maintenance & Service and Customization are in parameter groups (menu
l
indexes) 6 and 8 respectively.
The basic setup for external control signals and communication interfaces is done in parameter groups (menu indexes) 9 and 10
l
respectively.
Features and related parameters are grouped in individual parameter groups. Each feature has a parameter group of its own.
l
Status information for each parameter group is available separately for easy access.
l
The following table provides information about the parameter groups.
Menu index/Parameter group
1
2
3
4
Danfoss A/S © 2024.03
4 Motor
9 I/O
Parameter group name
Grid
Power Conversion
Filters & Brake Chopper
Motor
Description
Contains parameters for configuring, monitoring, and controlling the
energy source of the drive system. Typically, the energy source is the
grid. The menu also allows to configure grid protection settings and
view the condition of the grid.
Contains parameters to configure, monitor, and control the power
conversion of the drive. The menu allows to configure protection
settings of the power unit and settings for the rectifier, DC link, and
inverter.
Contains parameters to configure, monitor, and control the filters,
brake chopper, and brake resistors.
Contains parameters to configure motor, motor control, and motor
protection.
AB413939445838en-000301 / 130R1254 |
45
