Danfoss iC2 Application Manual page 236

Application Guide | iC2-Micro Frequency Converters
Selection number Selection name
0 Input
1 Output
P 9.4.2.2 T15 Digital Output
Select the function to control the digital output.
Default value:
0 [No Operation]
Parameter
530
number:
Data type:
enum
The following are the selections for the parameter.
Selection number Selection name
0 No Operation
1 Control Ready
2 Drive Ready
3 Drive Ready / Remote Mode
4 Stand-by / No Warning
5 Running
6 Running / No Warning
7 Run in Range / No Warning
8 Run on Ref. / No Warning
9 Fault
10 Fault or Warning
11 At Torque Limit
12 Out of Current Range
13 Below Current, Low
14 Above Current, High
236
| Danfoss A/S © 2024.03
Selection description
Defines terminal 15 as a digital input.
Defines terminal 15 as a digital output.
Parameter type:
Unit:
Access type:
Selection description
Default for all digital outputs.
The control card is ready.
The frequency converter is ready for operation and applies a
supply signal on the control board.
The frequency converter is ready for operation and is in Remote
mode.
Ready for operation. No start or stop command is given (start/
disable). No warnings are active.
The motor is running and shaft torque is present.
The motor is running and there are no warnings.
The motor is running within the programmed current and speed
ranges set in P 4.6.4 Warning Current Low to P 4.6.3 Warning
Current High. There are no warnings.
The motor runs at reference speed. No warnings.
A fault activates the output.
A fault or a warning activates the output.
The torque limit set in P 5.10.1 Motor Torque Limit or P 5.10.2
Regenerative Torque Limit has been exceeded.
The motor current is outside the range set in P 2.7.1 Output
Current Limit %.
The motor current is lower than set in P 4.6.4 Warning Current
Low.
The motor current is higher than set in P 4.6.3 Warning Current
High.
Selection
–
Read/Write
AB413939445838en-000301 / 130R1254
