Danfoss iC2 Application Manual page 278

Application Guide | iC2-Micro Frequency Converters
Group index Group name
4.4.3 U/F Curve
4.4.4 Dependent Setting
4.4.5 Dead Time Compensation
4.6 Protection
278
| Danfoss A/S © 2024.03
Parameter Parameter name
index
4.4.2.2 AC Brake, Max current
4.4.2.3 AC-Brake Voltage Control Kp
4.4.3.1 Voltage Point
4.4.3.2 Frequency Point
4.4.4.1 Slip Comp. Gain
4.4.4.2 Slip Comp. Time Constant
4.4.4.3 High Speed Load Comp.
4.4.4.4 Low Speed Load Comp.
4.4.4.5 Res. Damp Gain
4.4.4.6 Res. Damp High Pass Time Constant
4.4.4.7 Damping Gain
4.4.4.8 High Speed Filter Time Const.
4.4.4.9 Low Speed Filter Time Const.
4.4.4.10 Voltage Filter Time Const.
4.4.4.11 Variable Torque Zero Speed Magne-
tization
4.4.4.12 Min Speed Normal Magnetizing
[Hz]
4.4.4.13 VT Level
4.4.4.14 Min. Current at Low Speed
4.4.5.1 Dead Time Compensation Level
4.4.5.2 Dead Time Bias Current Level
4.4.5.3 Dead Time Compensation Zero Cur-
rent Level
4.4.5.4 Speed Derate Dead Time Compen-
sation
4.6.1 Warning Freq. High
4.6.2 Warning Freq. Low
4.6.3 Warning Current High
4.6.4 Warning Current Low
Parameter Type
number
216 uint16
188 uint16
155 uint16
156 uint16
162 int16
163 uint16
161 int16
160 int16
164 uint16
165 uint16
114 int16
116 uint16
115 uint16
117 uint16
150 uint16
152 uint16
1440 uint8
166 uint32
1407 uint8
1409 uint8
1464 enum
1465 uint16
441 uint16
440 uint16
451 uint32
450 uint32
AB413939445838en-000301 / 130R1254
