Application Guide | iC2-Micro Frequency Converters
Group index
Group name
2.5
DC-Link Control
2.7
Output Current Limit
3
Filters & Brake Chopper
3.1
Status
3.2
Brake Chopper
3.3
Brake Resistor
4
Motor
4.1
Status
4.2
Motor Data
4.2.1
General Setting
276
| Danfoss A/S © 2024.03
Parameter
Parameter name
index
2.4.5
Over Modulation
2.5.1
Damping Gain Factor
2.5.2
DC-Link Voltage Compensation
2.7.1
Output Current Limit %
2.7.2
Current Limit Kp
2.7.3
Current Limit Ti
2.7.4
Current Lim Ctrl, Filter Time
2.7.5
Trip Delay at Current Limit
3.1.1
Brake Energy
3.2.1
Enable Brake Chopper
3.2.2
Brake Chopper Voltage Reduce
3.3.2
Brake Resistor Value
3.3.3
Brake Resistor Power Limit
4.1.1
Motor Current
4.1.2
Motor Voltage
4.1.3
Motor Electrical Power
4.1.4
Motor Power hp
4.1.5
Motor Thermal Load
4.1.6
Frequency
4.1.7
Frequency %
4.1.8
Motor Shaft Speed
4.1.10
Motor Torque
4.1.11
Motor Torque %
Parameter
Type
number
1403
enum
1408
uint8
1451
enum
418
uint16
1430
uint16
1431
uint16
1432
uint16
1424
uint8
1633
uint32
215
enum
214
uint16
211
uint16
212
uint32
1614
uint16
1612
uint32
1610
uint32
1611
uint32
1618
uint8
1613
uint32
1615
uint16
1617
int32
1616
int32
1622
int16
AB413939445838en-000301 / 130R1254
