Application Guide | iC2-Micro Frequency Converters
Parameter
440
number:
Data type:
uint16
P 4.6.3 Warning Current High
Enter the I-high value. When the motor current exceeds this limit, a bit in the drives status word is set. This value can also be
programmed to produce a signal on the digital output or the relay output.
Default value:
Size Related
Parameter
451
number:
Data type:
uint32
P 4.6.4 Warning Current Low
Enter the I-low value. When the motor current falls below this limit, a bit in the drives status word is set. This value can also be
programmed to produce a signal on the digital output or the relay output.
Default value:
0.00
Parameter
450
number:
Data type:
uint32
P 4.6.7 Motor Thermal Protection
Motor thermal protection can be implemented via a PTC sensor in the motor windings connected to 1 of the analog or digital inputs (P
4.6.8 Thermistor Source). Or via calculation (ETR = Electronic Thermal Relay) of the thermal load, based on the actual load and time. The
calculated thermal load is compared with the rated motor current I
overheat warning or fault.
Default value:
0 [No Protection]
Parameter
190
number:
Data type:
enum
Selection number
Selection name
0
No Protection
1
Thermistor Warning
2
Thermistor Trip
Danfoss A/S © 2024.03
Unit:
Access type:
Parameter type:
Unit:
Access type:
Parameter type:
Unit:
Access type:
, and the rated motor frequency f
M,N
Parameter type:
Unit:
Access type:
Selection description
Continuously overloaded motor, when no warning or trip of the
frequency converter is required.
Activates a warning when the connected thermistor in the motor
reacts to a motor overtemperature.
Stops (trips) the frequency converter when the connected
thermistor in the motor reacts to a motor overtemperature. The
thermistor cut out value must be >3 kΩ. Integrate a thermistor
(PTC sensor) in the motor for winding protection.
Hz
Read/Write
Range (Size Related)
A
Read/Write
Range (Size Related)
A
Read/Write
. It is possible to activate an
M,N
Selection
–
Read/Write
AB413939445838en-000301 / 130R1254 |
137
