Table 17: Default Settings (continued)
Category
External reference
Preset refer.
Jog
Reference limits
Table 18: Parameter P 5.5.3.10 Preset Reference Setting (Array Type)
Reference
Preset Reference 0
Preset Reference 1
Preset Reference 2
Preset Reference 3

Configuring Wire Control Mode

5.5.5
3-Wire Control Mode of the drive enables to imitate the common contactor control circuit to control the motor. This is possible by using
2 momentary push-buttons to control motor start and motor stop. Reversing is controlled by 1 digital input.
Danfoss A/S © 2024.03
Parameter index Parameter name
5.5.3.7 Reference 1 Source
5.5.3.8 Reference 2 Source
5.5.3.9 Reference 3 Source
5.5.3.10 Preset Reference
5.9.2 Jog Reference
5.9.1 Jog Ramp Time
5.5.3.3 Reference Maximum
5.5.3.4 Reference Minimum
DI4 (Terminal 18)
[17] Preset Ref Bit [1]
0
0
1
1
Default setting Parameter number
[0] No Function 315
[0] No Function 316
[0] No Function 317
Note: Set as array
310
type Table 18.
5.0 311
3 s 380
50. If [1] North Amer- 303
ica is selected for
P 1.2.1 Regional
Settings, the default
value is 60.
0 302
DI3 (Terminal 17)
[16] Preset Ref Bit [0]
0
1
0
1
